2020 BOBCAT S76 -In Transit

Year: 2020 Make: Bobcat

Model: S76

Hours: 756

Serial Number: B4CD11349

Machine Specifications

• Engine: Bobcat turbocharged diesel

• Horsepower: 74 HP

• Emissions: EPA Tier 4 Final

• Rated Operating Capacity (ROC): 2,900 lbs

• ROC with 200 lb counterweight: 3,050 lbs

• ROC with 300 lb counterweight: 3,100 lbs

• Tipping Load: 5,800 lbs

• Operating Weight: 8,615 lbs

• Lift Path: Vertical lift

• Maximum Lift Height: 128.3 inches to hinge pin

• Reach at Maximum Height: 33.5 inches

Hydraulic System

• Standard Auxiliary Flow: 23.3 GPM

• High-Flow Auxiliary Hydraulics: 30.3 GPM (if equipped)

• Hydraulic System Pressure: 3,500 PSI

• Quick-Attach System: Bob-Tach

• Attachment Compatibility: Supports a wide range of hydraulic and standard skid-steer attachments

Dimensions & Performance

• Overall Width: 72 inches without bucket

• Width with Bucket: Approximately 74 inches

• Overall Height: 81.8 inches

• Length without Attachment: 113.9 inches

• Length with Standard Bucket: 147.1 inches

• Fuel Tank Capacity: 31.7 gallons

• Travel Speed: 6.8 MPH standard; up to 11.8 MPH with optional two-speed travel

Cab & Features

• Enclosed operator cab

• Heat and air conditioning

• Selectable joystick controls (if equipped)

• Keyless start

• LED front and rear work lights

• Adjustable operator seat

• Backup alarm

• Optional ride control

• Optional power Bob-Tach
