2016 Bobcat T650 Compact Track Loader — Specs

• Year: 2016

• Make: Bobcat

• Model: T650

• Hours :2357

• Machine Type: Compact Track Loader

• Engine: Turbocharged Kubota V3307 diesel

• Horsepower: 74.3 HP

• Emissions: Tier 4

• Rated Operating Capacity (ROC): 2,570 lbs

• Tipping Load: Approximately 7,170 lbs

• Operating Weight: Approximately 8,990 lbs

• Lift Path: Vertical lift

• Lift Height to Hinge Pin: 124 inches

• Reach at Maximum Height: Approximately 34–36 inches

Hydraulic System

• Standard Auxiliary Flow: 23 GPM

• High-Flow Auxiliary Hydraulics: 30.5 GPM (if equipped)

• Hydraulic System Pressure: Approximately 3,450 PSI at quick couplers

• Auxiliary Hydraulic Pressure: 3,500 PSI

• Attachment Mounting: Bob-Tach quick-attach system

• Attachment Compatibility: Compatible with a wide range of skid-steer attachments

Dimensions & Performance

• Overall Width: 72.9 inches

• Overall Height: 81.3 inches

• Length Without Attachment: 108.4 inches

• Length with Standard Bucket: 136.8 inches

• Fuel Tank Capacity: Approximately 27.2 gallons

• Standard Travel Speed: Approximately 6.2 MPH

• High-Speed Travel: Up to 8.7 MPH with optional two-speed travel

• Track Width: Verify installed track option; multiple track configurations were available.

Cab & Features

• Vertical lift design for loading trucks and placing material

• Turbocharged diesel engine

• Rubber track undercarriage

• Bob-Tach attachment mounting system

• Auxiliary hydraulic connections

• ROPS/FOPS operator protection

• Front and rear work lights

• Optional enclosed cab with heat and air conditioning

• Optional high-flow hydraulics

• Optional two-speed travel

• Optional selectable joystick controls
