2011 Bobcat S70 Skid-Steer Loader

Year: 2011 Make: Bobcat Model: S70

Hours: 545

Machine Specifications

• Engine: Kubota diesel

• Horsepower: 23.5 HP

• Rated Operating Capacity (ROC): 700 lbs

• Tipping Load: 1,512 lbs

• Operating Weight: Approximately 2,795 lbs

• Lift Path: Radius lift

• Maximum Lift Height to Hinge Pin: 94.5 inches

• Reach at Maximum Height: 15.8 inches

Hydraulic System

• Standard Auxiliary Flow: 9.8 GPM

• Hydraulic System Pressure: 3,000 PSI

• Auxiliary Hydraulic Pressure: 2,000 PSI

• Quick-Attach System: Bob-Tach

• Attachment Compatibility: Compatible with a variety of compact skid-steer attachments

Dimensions & Performance

• Overall Width: 35.5 inches

• Width with Bucket: Approximately 36 inches

• Overall Height: 71.4 inches

• Length Without Attachment: 75.6 inches

• Length with Standard Bucket: Approximately 97.3 inches

• Travel Speed: Approximately 6.1 MPH

• Fuel Tank Capacity: Approximately 6.5 gallons

• Standard Bucket Width: Approximately 36 inches

Features

• Compact design for tight-access jobs

• Hand and foot controls

• Bob-Tach attachment mounting system

• Auxiliary hydraulics

• ROPS/FOPS operator protection structure

• Lift-arm support for servicing

• Front work lights

• Optional enclosed cab with heat
